Description
Extruded aluminum full-length U bracket for 1/2-inch-thick commercial restroom partition material. Model 5203 can be matched to your existing toilet stall hardware by panel thickness, bracket dimensions, and mounting hole placement.
What is included
Includes one U bracket with security 6-lobe mounting fasteners.
Specifications
- Model: 5203
- Material: Extruded aluminum
- Fits partition material: 1/2 inch thick
- Bracket height: 1-3/8 inches
- Base width: 3/4 inches
- Bracket length: 41 inches
- Bracket quantity: 1 bracket
Check the fit before ordering
Measure your partition material and compare the bracket dimensions and mounting hole locations with your existing hardware. Match the material thickness listed above to your panel or pilaster thickness.
Typical installation
Full-length U brackets run vertically along the pilaster-to-panel connection to capture the panel edge. The bracket base attaches to the rear face of the front pilaster, and its two sides capture the divider panel edge. Follow the partition manufacturer's drawings for bracket length, mounting location, hole spacing, and fasteners.
Moisture suitability
Aluminum hardware is used in commercial restroom partition systems. For shower areas, frequent direct wetting, poolside use, or washdown cleaning, contact TPH Supply to confirm the alloy, surface finish, and mounting fasteners are appropriate. Wet-location suitability depends on the finish, exposure, and cleaning products.
